The Leica iCON iCS20 is an easy-to-use 3D measurement and layout tool, that serves a wide variety of professional applications.
It is particularly suitable for users who want to move from traditional, manual measurement and layout methods to digital workflows. Visual measurement technology always displays the current situation and prevents anything from being forgotten. Automated work...
The Leica iCON iCS20 is an easy-to-use 3D measurement and layout tool, that serves a wide variety of professional applications.
It is particularly suitable for users who want to move from traditional, manual measurement and layout methods to digital workflows. Visual measurement technology always displays the current situation and prevents anything from being forgotten. Automated workflows, as well as the intuitive, industry-specific software Leica iCON trades, also reduce measurement complexity to a minimum.
Areas of application:
- As-built measurements with all details for interior finishing, e.g. kitchen building, staircase construction, window and door installation
- MEP layout of hanger locations for HVAC and duct work, inserts and slits for sheet metal work
- Fully automatic layout routines of points on the floor or ceiling and lines for pipe wall penetrations
Your advantages:
- One-person operation reduces staff resources and increases productivity
- Simplified layout and measurement process due to visual measurement technology
- Quickly ready for use due to the automated set-up process
- Easy relocation with Leica vTargets
- Fast and efficient data capturing with all details for interior finishing
- Automated line and area scans for curved or complex objects
- Easy-to-use, industry-specific Leica iCON trades software for efficient workflows, seamless data flow and clear documentation
Ready for Use in Just a Few Steps
Due to its compact size and wireless connectivity, you can carry the Leica iCON iCS20 onto site, set it up, and operate it on your own – without the need for a second person. Smart features such as the ‘quick-mount’ tripod or the ‘auto-setup’ process ensure that the device is ready to use in just a few steps and help to avoid mistakes.
Fast Layout and Aiming
The camera live stream delivers extremely sharp images. This allows you to see on the tablet what the Leica iCON iCS20 sees and to select any point accurately. Due to the unique high-speed motor, the construction tool then locates that point very quickly with the bright pointing laser, shortening layout and measurement processes.
Line and Area Scans
This function simplifies capturing complex contours, such as door arches or rooms with uneven walls. Define the measurement range by a start and end point, as well as the measurement interval. The Leica iCON iCS20 automatically scans the measurement area and provides highly accurate results.
Leica vTarget - Easy Relocation
The visual-based target detection and the automated process greatly simplify the relocation of the device. New Leica vTargets are automatically detected. This saves you time, avoids errors and allows you to quickly continue your layout and measurement tasks even after a break. It also ensures best line of sight by always placing the device close to the working area.
Error Prevention
Active and continuous monitoring of the unit's position automatically detects even the smallest movement and triggers an alarm. This avoids inaccuracies and expensive mistakes, allowing you to work more environmentally friendly.
Technical Data
| 3D Point Accuracy | ||
|---|---|---|
Laser Combination of angle and distance measurement
|
1.0 mm @ 10 m (0.04 in @ 33 ft)
2.5 mm @ 50 m (0.10 in @ 164 ft) 10.5 mm @ 250 m (0.41 in @ 820 ft)* |
1.0 mm @ 10 m (0.04 in @ 33 ft)
2.0 mm @ 50 m (0.08 in @ 164 ft) 8.0 mm @ 250 m (0.31 in @ 820 ft)* |
vPen |
1.5 mm @ 10 m (0.06 in @ 33 ft)**
|
1.0 mm @ 10 m (0.04 in @ 33 ft)
|
vSphere |
3.0 mm @ 50 m (0.12 in @ 164 ft)**
|
1.0 mm @ 10 m (0.04 in @ 33 ft)
|
vPole tip |
3.0 mm @ 50 m (0.12 in @ 164 ft)****
|
3.0 mm @ 50 m (0.12 in @ 164 ft)****
|
| Angular Measurement | ||
Standard Deviation ISO 17123-3 Accuracy Hz and V
|
5" (1.54 mgon)
|
3" (0.93 mgon)
|
Working range |
horizontal (Hz): 360°, vertical (V): 290°
|
horizontal (Hz): 360°, vertical (V): 290°
|
| Distance Measurement | ||
Reflectorless range (Kodak White) Kodak White, 90% reflective
|
0.3 to 50 / 250 m (0.98 - 164 / 820 ft)*
|
0.3 to 50 / 250 m (0.98 - 164 / 820 ft)*
|
Reflectorless Range (Kodak Gray) Kodak Gray, 18% reflective
|
0.3 to 50 / 120 m (0.98 - 164 / 394 ft)*
|
0.3 to 50 / 120 m (0.98 - 164 / 394 ft)*
|
Standard prism (GPR1) Range |
3.0 to 50 / 250 m (9.84 - 164 / 820 ft)*
|
3.0 to 50 / 250 m (9.84 - 164 / 820 ft)*
|
Reflective tape (GZM31) Range |
1.0 to 50 / 150 m (3.28 - 164 / 492 ft)*
|
1.0 to 50 / 150 m (3.28 - 164 / 492 ft)*
|
vTarget (CVT3, CVT6) Range |
1.2 to 40 m (3.94 - 131 ft)***
|
1.2 to 40 m (3.94 - 131 ft)***
|
vPen Range |
0.7 to 10 m (2.30 - 33 ft)**
|
0.7 to 10 m (2.30 - 33 ft)**
|
vSphere Range |
1.5 to 50 m (4.92 - 164 ft)**
|
1.5 to 50 m (4.92 - 164 ft)**
|
Non-Prism / Any surface Accuracy |
1.0 mm @ 10 m (0.04 in @ 33 ft)
1.5 mm @ 50 m (0.06 in @ 164 ft) 6.0 mm @ 250 m (0.24 in @ 820 ft)* |
<1.0 mm @ 10 m (<0.04 in @ 33 ft)
1.5 mm @ 50 m (0.06 in @ 164 ft) 6.0 mm @ 250 m (0.24 in @ 820 ft)* |
Standard prism (GPR1) Accuracy |
1.5 mm @ 50 m (0.06 in @ 164 ft)
3.5 mm @ 250 m (0.14 in @ 820 ft)* |
1.5 mm @ 50 m (0.06 in @ 164 ft)
3.5 mm @ 250 m (0.14 in @ 820 ft)* |
Reflective tape (GZM31) Accuracy |
1.5 mm @ 50 m (0.06 in @ 164 ft)
2.5 mm @ 150 m (0.08 in @ 492 ft)* |
1.5 mm @ 50 m (0.06 in @ 164 ft)
2.5 mm @ 150 m (0.08 in @ 492 ft)* |
Laser dot size |
17.2 x 27.3 mm @ 50 m (0.68 in x 1.41 in @ 164 ft)
|
17.2 x 27.3 mm @ 50 m (0.68 in x 1.41 in @ 164 ft)
|
| Automatic Aiming | ||
Standard prism (GPR1) |
3.0 to 250 m (9.84 to 820 ft)*
|
3.0 to 250 m (9.84 to 820 ft)*
|
vTarget |
1.2 to 40 m (3.94 to 131 ft)***
|
1.2 to 40 m (3.94 to 131 ft)***
|
| Camera | ||
Overview camera (diagonal) FOV |
27.6° (4.91 m @ 10 m / 16 ft @ 33 ft) / 12.33 MP
|
27.6° (4.91 m @ 10 m / 16 ft @ 33 ft) / 12.33 MP
|
On-Axis camera (diagonal) FOV |
7.5° (1.31 m @ 10 m / 4.29 ft @ 33 ft) / 12.33 MP
|
7.5° (1.31 m @ 10 m / 4.29 ft @ 33 ft) / 12.33 MP
|
Fish-eye camera (circular) FOV |
~200° (circular) / 13.31 MP
|
~200° (circular) / 13.31 MP
|
Zoom |
16x
|
16x
|
| General | ||
Motorization |
Motorized (robotic upgrade possible)
|
Robotic
|
Direct drives |
180°/s
|
180°/s
|
Tilt compensation range |
±3°
|
±3°
|
Interfaces |
USB-C (2.0), WLAN
|
USB-C (2.0), WLAN
|
Weight |
3.37 kg | 7.43 lb
|
3.37 kg | 7.43 lb
|
Dust / Water / Humidity Rating |
IP54
|
IP54
|
Operating temperature |
-20°C to +50°C | -4°F to +122°F
|
-20°C to +50°C | -4°F to +122°F
|
Charging temperature |
0°C to +60°C | 32°F to +140°F
|
0°C to +60°C | 32°F to +140°F
|
Storage temperature |
-25°C to +70°C | -13°F to +158°F
|
-25°C to +70°C | -13°F to +158°F
|
| Power Management | ||
Battery |
Rechargeable Li-Ion
|
Rechargeable Li-Ion
|
Operating Time |
> 8h
|
> 8h
|
Charging Time |
70% in 1h, 100% in 2h
|
70% in 1h, 100% in 2h
|
| 3D Point Accuracy | |
|---|---|
Laser Combination of angle and distance measurement
|
1.0 mm @ 10 m (0.04 in @ 33 ft)
2.5 mm @ 50 m (0.10 in @ 164 ft) 10.5 mm @ 250 m (0.41 in @ 820 ft)* |
vPen |
1.5 mm @ 10 m (0.06 in @ 33 ft)**
|
vSphere |
3.0 mm @ 50 m (0.12 in @ 164 ft)**
|
vPole tip |
3.0 mm @ 50 m (0.12 in @ 164 ft)****
|
| Angular Measurement | |
Standard Deviation ISO 17123-3 Accuracy Hz and V
|
5" (1.54 mgon)
|
Working range |
horizontal (Hz): 360°, vertical (V): 290°
|
| Distance Measurement | |
Reflectorless range (Kodak White) Kodak White, 90% reflective
|
0.3 to 50 / 250 m (0.98 - 164 / 820 ft)*
|
Reflectorless Range (Kodak Gray) Kodak Gray, 18% reflective
|
0.3 to 50 / 120 m (0.98 - 164 / 394 ft)*
|
Standard prism (GPR1) Range |
3.0 to 50 / 250 m (9.84 - 164 / 820 ft)*
|
Reflective tape (GZM31) Range |
1.0 to 50 / 150 m (3.28 - 164 / 492 ft)*
|
vTarget (CVT3, CVT6) Range |
1.2 to 40 m (3.94 - 131 ft)***
|
vPen Range |
0.7 to 10 m (2.30 - 33 ft)**
|
vSphere Range |
1.5 to 50 m (4.92 - 164 ft)**
|
Non-Prism / Any surface Accuracy |
1.0 mm @ 10 m (0.04 in @ 33 ft)
1.5 mm @ 50 m (0.06 in @ 164 ft) 6.0 mm @ 250 m (0.24 in @ 820 ft)* |
Standard prism (GPR1) Accuracy |
1.5 mm @ 50 m (0.06 in @ 164 ft)
3.5 mm @ 250 m (0.14 in @ 820 ft)* |
Reflective tape (GZM31) Accuracy |
1.5 mm @ 50 m (0.06 in @ 164 ft)
2.5 mm @ 150 m (0.08 in @ 492 ft)* |
Laser dot size |
17.2 x 27.3 mm @ 50 m (0.68 in x 1.41 in @ 164 ft)
|
| Automatic Aiming | |
Standard prism (GPR1) |
3.0 to 250 m (9.84 to 820 ft)*
|
vTarget |
1.2 to 40 m (3.94 to 131 ft)***
|
| Camera | |
Overview camera (diagonal) FOV |
27.6° (4.91 m @ 10 m / 16 ft @ 33 ft) / 12.33 MP
|
On-Axis camera (diagonal) FOV |
7.5° (1.31 m @ 10 m / 4.29 ft @ 33 ft) / 12.33 MP
|
Fish-eye camera (circular) FOV |
~200° (circular) / 13.31 MP
|
Zoom |
16x
|
| General | |
Motorization |
Motorized (robotic upgrade possible)
|
Direct drives |
180°/s
|
Tilt compensation range |
±3°
|
Interfaces |
USB-C (2.0), WLAN
|
Weight |
3.37 kg | 7.43 lb
|
Dust / Water / Humidity Rating |
IP54
|
Operating temperature |
-20°C to +50°C | -4°F to +122°F
|
Charging temperature |
0°C to +60°C | 32°F to +140°F
|
Storage temperature |
-25°C to +70°C | -13°F to +158°F
|
| Power Management | |
Battery |
Rechargeable Li-Ion
|
Operating Time |
> 8h
|
Charging Time |
70% in 1h, 100% in 2h
|
| Notes | |
Notes |
* iCS 250 m option required.
** iCS20 requires iCS Robotic option *** With rough aiming with the camera. Fully autonomous detection from 2 m / 6.56 ft to 25 m / 82 ft. **** Including tilt compensation with vSphere at H3. |
